Kjøp brukt Wolters (2)

Tilstand: god (brukt), Peter Wolters AC500 Lapping Machine TECHNICAL DATA AND SCOPE OF DELIVERY TECHNICAL DATA Gear mechanism size: 42 TS 7/14 Working disc diameter: 415 mm Ring width: 54 mm Working disc thickness: 50 mm Possible disc wear up to approx.: 20 mm Number of runners: 14 Drive data: 380 V / 50 Hz Upper disc drive: 1.0 / 1.4 kW Worm gear motor: 56 / 112 rpm Lower disc drive: 1.0 / 1.4 kW Worm gear motor: 500 / 100 rpm Workpiece drive: 0.5 / 0.7 / 0.9 kW 3-pole worm gear motor: 6 / 18 / 36 rpm Pivot arm drive: 0.25 kW Digital load adjustment of the upper working disc: 0-250 daN Connection data Electrical connection: 5.0 kW Compressed air connection: 5-7 bar Compressed air consumption: approx. 8 Nl/min SCOPE OF DELIVERY Includes (not an exhaustive list): Peter Wolters AC 500 lapping machine / fine grinding machine Cedpfstxitvex Anrogt 1 frequency converter per motor Documentation Exact scope of delivery as per photo series No guarantee is given for the accuracy, completeness or timeliness of the information provided.

Tilstand: brukt, Byggeår: 2001, Funksjonalitet: fullt funksjonell, maskin-/kjøretøynummer: 11087, type innstrømsstrøm: Klimaanlegg, 2-skive finslipesmaskin med tilbehør. God stand. Med heiseanlegg. Komplett dokumentasjon. Csdpfeq Nitvjx Anrjgt
