MAGNI Magni ES2223RTP 22m Scherenbühne Megadeck 3x

Magni ES2223RTP 22m Electric Scissor Lift Megadeck

- Automatic stabilizers for working at height
- Self-locking platform door
- Speed limitation at maximum height
- Platform overload control
- Automatic braking system
- Non-marking tires
- Tilt indicator with alarm
- Audible lowering alarm and double LED strobe light
- Safety bar for maintenance work
- Horn
- Emergency stop button
- Emergency lowering system
- Tie-down points
- On-board diagnostic system
- Hour meter
- Proportional controls
- Foldable guardrails
- Power supply on platform
- Explosion-protected hoses
- Motion alarm
- Charging protection system
- Lifting and securing points
- One-sided and automatic platform extension
- All-wheel drive
- 4-wheel steering
- Load-dependent lowering system
- Emergency hydraulic pump
Kwsdpsxl Nybsfx Afret

Capacity: 750 kg
Max. persons: 4
Working height: 22 m
Platform height: 20 m
Length: 4.95 m
Width: 2.46 m
Overall height (rails up): 3.86 m
Transport height (rails down): 3 m
Platform length: 4.95 m
Platform width: 2.25 m
Ground clearance: 40 cm
Wheelbase: 2,290 mm
Inside turning radius: 2.15 m
Outside turning radius: 4.85 m
Drive motors: 4×32VAC / 3.3 kW
Lift motors: 2×48VDC / 10.0 kW
Travel speed (stowed): 5 km/h
Travel speed (elevated): 0.40 km/h
Gradeability (max): 40%
Operating inclination: 2°/3°
Batteries: 48 V / 630 Ah

Errors and prior sale excepted.
Internal vehicle number: R58
