Lasersveisemaskin

SPAWARKA LASEROWA JSW 3000 - 3kW

Parameter: JSW-3000
Laser power: 3000W
Laser source lifespan: 100,000 hours
Laser wavelength: 1064 - 1070nm
Cable: 10m (15m available on request)
Operating temperature: -10 - 45℃
Operating environment humidity: 10 - 90%
Positioning: laser indicator (red dot or line)
Shielding gas: Nitrogen / Argon / Oxygen
Power supply: 3-phase 380V 50/60 Hz
Maximum total power consumption: 24.6KVA/37.4A
Average power consumption: 14.7KVA
Device status indication:
status indication for water chiller, protective mirror temperature, controller temperature
Welded sheet thickness: 0.5 - 8mm
Maximum gap width: ≤2mm
Laser beam width for cleaning function: 0 - 70mm
Cooling method: water cooled
Control method: touch panel / monitor and PLC
Wire feeder – fully automated
Device weight: 195kg
Machine dimensions:
Height: 1050mm,
Width: 530mm,
Length: 1240mm.

Material processing capabilities for JSW 3000W welding function
Material:
Stainless steel 0.5 - 8mm
Carbon steel 0.5 - 8mm
Galvanized sheet 0.5 - 8mm
Aluminum 0.5 - 6mm

Price includes:
• Selected JSW welding system
• Laser source [MAXPhotonics or Raycus]
• Automated wire feeder
Credpjtwz Nmefx Ah Djh
• Working gun with modes:
welding, cleaning, cutting
• Integrated cooling system
• Touch panel controller with Polish language menu
• Set of welding nozzles
• Spare protective glasses
• OD6+ protective goggles
• OD8+ welding mask
• 24-month warranty
