Kombinert maskin

Holzprofi 7-SF2-2,3VR4kW-OA-IG

Aluminum format sliding carriage with hardened steel guide rods.
Telescopic crosscut stop 1800 mm with two stop flaps as standard.
Stable cantilever table for processing heavy panels.
Rip stop with micrometric fine adjustment.
Milling spindle and saw blade can be completely retracted.
Replaceable milling spindle with MK4 holder
With its own motor for the scoring unit for easy switching off.

100% Made in EU (developed, built, quality-tested)

Technical data:

Circular saw:
max. saw blade diameter 315 mm
spindle diameter 30 mm
max. cutting width on parallel stop 1100 mm
max. cutting height, 90°/45° 103 mm/72 mm
motor output 5 kW S6 (4 Kw S1)
extraction nozzle diameter 120 mm

milling machine:
spindle diameter 30 mm
pivoting spindle 90°/45°
height adjustment of the spindle 175 mm
spindle speed 10000/8000/6000/
5000/4000/3000
motor output 5 kW S6 (4 Kw S1)
Iajlhcdwjvrvdqo Eet
weight 790 kg

With special accessories:
format table length 2300 mm, scoring unit,
4 kW Motor, integral stop 500 mm, upper suction,
degree grid on the delivery table

Special accessories Optional:
Change spindle for router
Longer format sliding table (2500 - 3200 mm)
